·技术参数
| 型号： Model |
ZJY0.2-1.8×500
|
ZJY0.3-2.0×1250(1600)
|
ZJY1.0-6.0×1600
|
ZJY3.0-12.0×2000
|
| 钢卷材质：Coil Material |
δs≤230N/mm2,Cold-rolled Coil,Hot-rolled Coil,Steel Coil,Galvanized Coil 冷轧、热轧钢卷、不锈钢卷、镀锌钢卷 |
| 钢卷厚度：Coil Thickness |
0.2~1.8mm
|
0.3~2.0mm
|
1.0~6.0mm
|
3.0~12.0mm
|
| 钢卷宽度：Coil Width |
100~500mm
|
800~1250mm(1600mm)
|
800~1600mm
|
1000~2000mm
|
| 钢卷重量：Coil Weight |
≤5T
|
≤20T(25T)
|
≤25T
|
≤30T
|
| 钢卷内径：Coil I.D |
φ508mm
|
φ508mm
|
φ508mm,φ610mm,φ760mm
|
φ610mm,φ760mm,φ820mm
|
| 钢卷外径：Coil O.D |
≤φ1600mm
|
≤φ2000mm
|
φ≤2000mm
|
φ≤2000mm
|
| 分条宽度：Strip Width |
≥25mm
|
≥30mm
|
≥50mm
|
≥80mm
|
| 分切条数：Number of Strip |
5~15
|
8~20
|
5~15
|
4~15
|
| 分切精度：Slitting Accuracy |
±0.1mm
|
±0.15mm
|
±0.25mm
|
±0.3mm
|
| 线速度： Line Speed |
0~60m/min
|
0~150m/min
|
0~60m/min
|
0~60m/min
|
| 控制系统：Electrical Control System |
PLC Automatic control
|
PLC Automatic control
|
PLC Automatic control
|
PLC Automatic control
|
| 电源： Standard power source |
380V50Hz
|
380V50Hz
|
380V50Hz
|
380V50Hz
|
|
